Product Details:
|
| Screw No: | Double-screw | Condition: | New |
|---|---|---|---|
| Motor: | SIMENS | Gurantee: | 1 Year |
| Specification: | 16-800mm | Computerizedd: | Computerized |
| High Light: | 16mm Corrugated Pipe Extrusion Line,120kg/H Corrugated Pipe Extrusion Line,8m/Min Corrugated Pipe Extrusion Line |
||
PVC PE Double Flexible Corrugated Electrical Cable Protection Pipe Extrusion Making Machine
| Model | Pipe range(mm) | Extruder model | Capacity(kg/h) | Speed(m/min) |
| WS-63 | 16-63 | SJZ51/105 | 120 | 1.5-15 |
| WS-110 | 20-110 | SJZ51/105 | 120 | 0.8-8 |
| WS-160 | 50-160 | SJZ55/110 | 180 | 0.5-5 |
| WS-250 | 75-250 | SJZ65/132 | 300 | 0.4-4 |
| WS-315 | 110-315 | SJZ80/156 | 450 | 0.3-2 |
| WS-450 | 200-450 | SJZ92/188 | 650 | 0.1-1 |
| WS-630 | 315-630 | SJZ92/188 | 800 | 0.07-0.7 |
The PVC PE Double Flexible Corrugated Electrical Cable Protection Pipe Extrusion Making Machine is a kind of special equipment for raw material PVC powder to extrude pipe.
The screw has applied oil cooling system, barrel is cooled by special wind cooling system, and the system is specially compute controlled. According to customer's requirements, most reasonable screw can be made in order to achieve best plasticity state and material quality, that is easier to extrude pipe.
For different diameter range pipe,will be equipped with corresponding different production lines.
we can supply PVC pipe production lines for diameter:
16mm,20mm,25mm,32mm,40mm,50mm,
63mm,75mm,90mm,110mm,125mm,160mm,200mm,
250mm,280mm,315mm,
355mm,400mm,450mm,500mm,550mm,
630mm,710mm,800mm.
Each different pipe production line will include:
screw conveyor+mixer+spring conveyor+conical twin screw extruder+mould+vacuum forming tank+haul off machine+cutting machine(knife lift cutter for small pipe; planetary cutter for big pipe)+stacker
