Product Details:
|
| Plastic Processed: | PVC | Screw No: | Double-screw |
|---|---|---|---|
| Screw Material: | 38CrMoALA | Screw L/D Ratio: | 33:1 |
| Warranty: | 1 Year | Customized: | Customized |
| High Light: | 160mm PVC Corrugated Pipe Extrusion Line,Twin Screw Corrugated Pipe Extruder,6m/Min Corrugated Pipe Extrusion Line |
||
20-160mm High Speed PVC Single Wall Corrugated Pipe Plastic Twin Screw Extrusion Line
| Model |
Diameter (mm) |
Extruder |
Main Motor Power (kw) |
Hauling Speed (m/min) |
Output (kg/h) |
| FST-PVC63-S | 16-63 | SJSZ51/105 | AC18.5 | 10 | 120 |
| FST-PVC63-D | 16-63 | SJSZ65/132 | AC37 | 15 | 250 |
| FST-PVC160 | 75-160 | SJSZ65/132 | AC37 | 6 | 250 |
| FST-PVC315 | 110-315 | SJSZ80/156 | AC55 | 4 | 360 |
| FST-PVC630 | 315-630 | SJSZ92/188 | DC110 | 1.2 | 800 |
| FST-PVC800 | 500-800 | SJSZ105/216 | DC185 | 0.9 | 1450 |
The application for 20-160mm High Speed PVC Single Wall Corrugated Pipe Plastic Twin Screw Extrusion Line
1 Advanced machine design.
Machine designed according to customer formula and final product to ensure high capacity and perfect plasticization.
Eqiupped with energy saving component and reasonble design, the extruder is energy saving.
1. High quality screw and barrel can be matched by ourselves.
2. The soft plastic design concept,ensures the quality of material.
3. Very reliable and effective design theoty,ensures the extrusion operation.
4.The new development of the screw,suitable for formulation of the high amount of filler,guarantee the material in screw good filling degree and the best distribution of material flow.
5. Screw with core temperature regulating device and a well barrel cooling,ensure the accurate control of the temperature of material process.
6. Match different dies and materials for extrusion molding all kinds of pipe,plate,profile and soft(hard) PVC granulation.
