Product Details:
|
| Plastic Processed: | PP PE | Screw No.: | Single-screw |
|---|---|---|---|
| Output: | 60-100g/h | Motor Power: | 37kw |
| Automation: | Automatic | Warranty: | 1 Year |
| High Light: | Corrugated Pipe Extrusion Line 100kg/H,20mm Pipe Extrusion Line,SJ65 Single Wall Corrugated Pipe Extrusion Line |
||
60-100kg/H 20-63mm Single Wall Corrugated Pipe Extrusion Line
| Model | Pipe diameter(mm) | Extruder model | Output(kg/h) | Total power(kw) | Module No.(pairs) | Production line speed(m/min) |
| CMDB-12 | Φ6-12 | SJ-45 | 40-60 | 16 | 42 | 6-12 |
| CMDB-32 | Φ16-32 | SJ-50 | 50-70 | 23 | 48 | 6-12 |
| CMDB-63 | Φ20-63 | SJ-65 | 60-100 | 38 | 56 | 4-8 |
| CMDB-80 | Φ50-80 | SJ-75 | 70-130 | 64 | 72 | 3-8 |
60-100kg/H 20-63mm Single Wall Corrugated Pipe Extrusion Line consists of extruders, die head, corrugation forming machine with modules, coiler etc. and can produce different sizes of corrugated pipes.
Features:
1. Extruder: high efficient screw, hard gear surface gearbox, uniformed raw material heating, good plasticization, high extrusion speed.
2. Corrugation forming machine: closed structure, module link in the overall closure base does round-trip running in the running tunnels.
3. Forming modules: it is made of hard steel, dealed with a rigorous use of CNC finishing materials produced to ensure the hardness and precision of the molding modules. These modules are easy and convenient to change
4. Coiler :Single position or double position with torque motor.
5. Electrical parts: ABB inverter, Siemens contactor, RKC thermo controllers etc.
