Product Details:
|
| Screw Channel Structure: | Deep Screw | Engagement System: | Full Intermeshing |
|---|---|---|---|
| Computerized: | Computerized | Origin: | China |
| Plastic Processed: | PE | Specification: | 50-800mm |
| High Light: | HDPE Drainage Pipe Extrusion Machine,800mm Drainage Pipe Extrusion Machine,ABB Inverter Pipe Extrusion Machine |
||
Description:
Close type corrugator and vacuum forming.
Forming module is moving in a tunnel.
Forming tunnel is clod by water.
Forming module is made of hard alloy steel and anti-corrosion and abrasion.
No any connection between forming module, then reduce time to change.
Provide dingle sand double wall corrugation pipe head die.
Corrugated forming system with strong cooling ability ensures constant production with
high speed.
| Model | Pipe Diameter Range(mm) | Extruder | Production Speed (m/min) | Max Production(kg/h) | Power(kw) |
Dimensions (m) |
| SJPGZ-40 | Ø20-Ø40 | SJSZ-51/105 | 1-12 | 150 | 65 | 32x1.8x2 |
| SJPGZ-250 | Ø50-Ø250 | SJSZ-65/132 | 0.5-5 | 300 | 100 | 36x2x2 |
| SJPGZ-315 | Ø110-Ø315 | SJSZ-80/156 | 1-3.6 | 420 | 145 | 38x2x2 |
| SJPGZ-400 | Ø200-Ø400 | SJSZ-80/156 | 0.2-2 | 420 | 210 | 42x2.5x2.5 |
| SJPGZ-630 | Ø315-Ø630 | SJSZ-92/188 | 0.08-0.8 | 750 | 245 | 48x2.5x2.5 |
3.The mould surface is nitrided and polished. A wall thickness-regulating device is equipped
in die lip to be suitable for production of different raw materials and ring resistance materials.
4.Advanced on line socketing function lowers the investment and increases the efficiency.
5.Double Wall HDPE Agriculture Drainage Pipe PVC Corrugated Pipe Making/Extrusion Line adopts SIEMENS PLC computer controlled system with touched screen
Applications:
This Double Wall HDPE Agriculture Drainage Pipe PVC Corrugated Pipe Making/Extrusion Line is used to produce double wall corrugated pipe with PVC or PE as materials. This kind of pipe has unique structure and many advantages such as: light mass, impact resistance, corrosion endurance, cold and heat resistance. So, this kind pipe is widely used in the fields of communication, paving of wire and cable, agricultural irrigation, water supply and drainage in cities, geographic deep irrigation and feed water in architecture, etc.
| Model | Structure Form | Applicable Raw Materials | Pipe Diameter Range | Max Extrusion Output | Forming Speed |
| SW-1500 | Vertical | HDPE | 400-1500 | 1200 | 0.25-2.5 |
