Product Details:
|
| Driven Type: | Electric | Screw: | Single-Screw |
|---|---|---|---|
| Low-Voltage Electrical Parts: | Schneider | Inverter: | ABB |
| Extruding Capacity: | 270kg/H | Suitable Material: | PVC/PE |
| The Screw Diameter: | 150mm | Running Speed: | >40m/Min |
| High Light: | 270kg/H Cable Jacket Extrusion Machine,150mm Screw Cable Extrusion Machine,380V Cable Jacket Extrusion Machine |
||
Medium and Low Voltage Cable Conductor Cable Jacket Extrusion Machine
Main specification and performance
1,finished outer diameter:φ5.0-φ25.0mm
2,Extrusion output: 280kg/h the machine head is open
3,Wire coaxiality: above-95%
4,Line speed: according to wire diameter
5,Center height of machine: it is 1000mm from the ground
6,Power supply: AC380V.
7,Color:as customer's requirment
|
Model |
SW-70 |
SW-80 |
SW-90 |
SW-120 |
SW-150 |
|
Core wire dia |
1-8mm |
2-12mm |
4-16mm |
15-35 |
40-80 |
|
Heating power of the machine body |
20kw |
23kw |
27kw |
40kw |
60kw |
|
Driven force |
40hp |
60hp |
60hp |
100hp |
125hp |
|
Max.output (kg/h) |
140 |
180 |
240 |
380 |
500 |
The above is our main models. We also can customize the wire cable extrusion lines as per your requirements.
As of now we can make the following extrusion lines:
Micro-fine teflon extrusion line
Teflon high temperature electronic wire extrusion line
Triple-layer insulation extrusion line
Triple-layer insulation co-extrusion extrusion line
Chemical foaming double-layer extrusion line
Physical foaming extrusion line
High-speed automatic Lan Cable extrusion line
High speed insulation cored wire extrusion line
Nylon double-layer extrusion line
Jacket (sheath) extrusion line
Rubber continuous vulcanization extrusion line
Sillicone gel continuous vulcanization extrusion line
Radiation rubber wire extrusion line
High speed automobile wire extrusion line
