Product Details:
|
| Product Type: | PE PVC Pipe | Inverter: | ABB Brand |
|---|---|---|---|
| Contactor: | Schneider | Screw No.: | Single-screw |
| Pipe Range: | 315-500 Mm | ||
| High Light: | 500mm Corrugated Pipe Extrusion Line,1200kg/H Corrugated Pipe Extrusion Line,25mm Corrugated Pipe Extrusion Line |
||
Single Screw 500mm Corrugated Pipe Extrusion Line 1200kg/H
Product description of Single Screw 500mm Corrugated Pipe Extrusion Line 1200kg/H
| Pipe Size | Type | Extruder | Output |
| 9-32 mm | Single Wall | SW-65/30 | 40-60 kg/h |
| 50-160 mm | Single Wall / Doble Wall | SW-75/33+SW-65/33 | 150-200 kg/h, 200-300 kg/h |
| 200-800 mm | Double Wall | SW-120/33+SW-90/33 | 600-1200 kg/h |
| 800-1200 mm | Double Wall | SW-90/38+SW-75/38 | 1200-1500 kg/h |
Single Screw 500mm Corrugated Pipe Extrusion Line 1200kg/H can produce 9mm to 1200mm OD/ID corrugated pipe, which are widely used as cable protect cover, medical transfer pipe(small size corrugated pipe); gas transfer, water transfer (big size corrugated pipe) etc.
Automatic PP PE PVC Double Wall Corrugated Plastic Pipe Cable Extruder Making Machine consists of:
According to different material, could be use conical double screw extruder for PVC material, single screw extruder for PE/PP material.
Also extruder model choose according to pipe size & mould design. for example, PE 9mm to 25mm corrugated pipe, choose SJ65/30 single screw extruder for high speed design, or SJ55/30 single screw extruder for normal speed design.
And extruder QTY choose according to pipe design, single wall corrugated pipe use one extruder, double wall corrugated pipe need 2 sets extruder. such as PE 160mm single wall corrugated pipe production machine choose SJ75/33 single screw extruder, double wall type need choose SJ75/33 single screw extruder + SJ65/33 single screw extruder. as well as SJZ45/90 conical double screw extruder for small PVC single wall corrugated pipe extrusion.
According to client requirements, our extruder could be manufacture control by SIEMENS PLC, with SMATAC HMI.
