Product Details:
|
| Hardness: | Hard Tube | Type: | Thermosetting Plastic Pipe |
|---|---|---|---|
| Model NO.: | 315-500 Mm | Material: | PE |
| Types: | Double Wall | Screw: | Electrical Hydraulic Control |
| High Light: | FRPP Double Wall Corrugated Pipe,BS6920 Double Wall Corrugated Pipe,1.6MPa Double Wall Corrugated Pipe |
||
Large Diameter Construction Polyethylene HDPE Double Wall Corrugated Pipe
Application of Large Diameter Construction Polyethylene HDPE Double Wall Corrugated Pipe
Municipal engineering water supply system, building indoor water supply system, outdoor undergroundwater supply system and the residential area, plant areaunderground water supply system, old pipeline repair, water treatment engineering piping system, garden.
But it is important to note that FRPP pipe cannot be used for hot water pipe.
| Diameter DN/ID (mm) |
Minimum mean internal meridian Dim MIn(mm) |
Suggestion connection length(mm) | Minimum laminated wall thickness(mm) | Minimum inner wall thickness (mm) |
| 200 | 198 | 54 | 1.5 | 1.1 |
| 300 | 296 | 65 | 2.0 | 1.7 |
| 400 | 394 | 74 | 2.5 | 2.3 |
| 500 | 492 | 85 | 3.0 | 3.0 |
| 600 | 588 | 96 | 3.5 | 3.5 |
| 800 | 785 | 118 | 4.5 | 4.5 |
| 1000 | 985 | 140 | 5.0 | 5.0 |
| 1200 | 1185 | 162 | 5.0 | 5.0 |
Specifications of Large Diameter Construction Polyethylene HDPE Double Wall Corrugated Pipe
Material: high quality PE80 or PE100
Sizes: 20mm-630mm
Pressure Rating: 0.4MPa, 0.6MPa, 0.8MPa, 1.0MPa, 1.25MPa, 1.6MPa
Colors: blue, black or other colors on request
Connection: socket fusion joint, butt fusion joint, electro fusion joint, flanged joint
Standard: ISO 4429 and BS6920
Certification: ISO9001, ISO14001, OHSAS18001
Applications: water supply, industrial liquids transportation and sewage treatment, Internet Cable
Product Advantages:
Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
Corrosion Resistant: resist chemical matters or electron chemical corrosion
Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system
Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipe
Longevity: more than 50 years under proper use
Recycled and Environment-friendly.
