160mm Plastic Tube Making Machine

PE Pipe Extrusion Machine Line Plastic Pipe Production Line LDPE /PPR Electricity Conduit Tube


If you need to buy PE Pipe Extrusion Machine Line Plastic Pipe Production Line LDPE /PPR Electricity Conduit Tube, please contact us, Qingdao Win Win Machinery Manufacturing Co., Ltd., first-class quality, competitive price is your best choice!

The bellows equipment consists of:

Loading desiccant

Extruder (co extrusion)

Extruder head

Molding machine

Modular

Cooling water tank

cutting machine

Turning frame

PE Pipe Extrusion Machine Line Plastic Pipe Production Line LDPE /PPR Electricity Conduit Tube of Qingdao Win Win Machinery Co., Ltd. The tube production adopts the direct extrusion technology, which has high production efficiency and reliable quality. The products are made of PE, PP, PVC and other raw materials are produced.

Due to its excellent pipe wall structure design, PE Pipe Extrusion Machine Line Plastic Pipe Production Line LDPE /PPR Electricity Conduit Tube has the characteristics of high ring rigidity, light weight, high pressure resistance, good toughness, corrosion resistance, good wear resistance, convenient construction, low installation cost, long service life, etc., which greatly reduces the cost of pipe, improves the market competitiveness of pipe, and makes the connection convenient and reliable without special complex pipe fittings It has been widely used in China and has been widely replaced by traditional concrete pipe and cast iron pipe.

In China, with the increase of urban and rural infrastructure, the construction of sewage pipe network, the use of wire casing, farmland irrigation, underground filtration irrigation, double wall corrugated pipe has a huge market space and development prospects.

Performance characteristics of double wall corrugated pipe production line of Qingdao Win Win Machinery Co., Ltd.: The molding machine adopts the overall horizontal structure, covering a small area, and the ground does not need to be the foundation. The working platform has horizontal, vertical and horizontal adjustment mechanisms.

The PE Pipe Extrusion Machine Line Plastic Pipe Production Line LDPE /PPR Electricity Conduit Tube adopts high-efficiency double alloy screw, slotting barrel, ceramic heating ring, and the inner and outer layers of the corrugated pipe are separately fed by two extruders, which can realize the production of pipes with different raw materials for the inner and outer layers and ensure the high-efficiency extrusion;

The double-layer on-line expanding of extruder head is designed as double helix coextrusion feed, which is extruded separately through the double-layer die with adjustable gap.

The die (air-cooled + water-cooled) is made of special aluminum alloy, which has the advantages of light weight, high strength, good wear resistance and small coefficient of thermal expansion.

The PE Pipe Extrusion Machine Line Plastic Pipe Production Line LDPE /PPR Electricity Conduit Tube adopts a strong cooling corrugated forming system combining water cooling and air cooling, which can ensure a high production speed in continuous production. The advanced programmable lubrication system reduces the wear of the forming module to the minimum, greatly prolongs the service life, ensures the operation accuracy and ensures the stable quality of the pipe.

Double wall corrugated pipe production line adopts professional PLC computer control system, 15 "large screen color touch human-machine interface, high degree of automation, reliable operation and simple operation;

The On-line UPS battery ensures that the workbench can return automatically in case of sudden power failure and other faults, so as to separate the module from the water jacket.

PE Pipe Extrusion Machine Line Plastic Pipe Production Line LDPE /PPR Electricity Conduit Tube has passed CE safety certification organized by China Quality Certification Center.

The selection of Win Win people's equipment is equal to the success of selection. Our company has a professional technical team, strong after-sales guarantee, one-year equipment warranty, fast after-sales response, excellent service, complete accessories, and the company sends professional technicians to provide on-site service.
