200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR

200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR
200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR 200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR

Large Image :  200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR

Product Details:
Place of Origin: China
Brand Name: Win Win
Certification: CE
Model Number: SJ120/33
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 45 workdays
Payment Terms: T/T
Supply Ability: 50 sets/Month
Contact Now

200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR

Description
Specification: 200-500mm Speed: 2m/min
Screw: Single-screw Product Type: PE Pipe
Automation: Automatic Computerized: Computerized
High Light:

500mm Single Wall Corrugated Pipe Extrusion Line

,

200mm Single Wall Corrugated Pipe Extrusion Line

,

PPR Single Wall Corrugated Pipe Extrusion Line

200-500mm Plastic PVC/PE/PP/PPR Single Wall Corrugated Pipe Extrusion Line



Diameter range(mm) Extruder model Max.Capacity(kg/h) Max.lineal speed(m/min.) Extrusion power(KW)
20-63 ASS65/33 220 12 55
20-63 ASE60/38 460 30 110
20-63Dual ASE60/38 460 15*2 110
20-110 ASS65/38 220 12 55
20-110 ASE60/38 460 30 110
20-160 ASE60/38 460 15 110
50-250 ASE75/38 600 12 160
110-450 ASE90/38 850 8 250
250-630 ASE90/38 1050 4 280
500-800 ASE120/38 1300 2 355
710-1200 ASE75/38
ASE90/38		 1450 1 160
250
710-1200 ASE90/38
ASE90/38		 1900 0.6 280
280



Application of 200-500mm Plastic PVC/PE/PP/PPR Single Wall Corrugated Pipe Extrusion Line
PE Plastic Pipe Extrusion Line is mainly used in the production of agricultural drainage, water supply and cable conduit purposes. The unit consists of single extruder machine, mold, vacuum forming tank, multi-claw haul-off machine, planetary(chipless/non-dust cutter) cutting machine, stacker and so on. And the line can be equipped with Comptroller thickening instrument or computer ink-jet printer, etc. to achieve the production and manufacture of high-grade tubing.

Great advantages of 200-500mm Plastic PVC/PE/PP/PPR Single Wall Corrugated Pipe Extrusion Line
1. High lineal extrusion speed, big capacity and low power consumption, and achieved multi-layers co-extrusion with 1-5 layers.
2. The copper bush is more wear-resisting and prevent material leakage which can guarantee a stable running of extruder.
3. Material feed via spiral groove, efficient transmission and can effectively reduce back-pressure on extruder.
4. Unique design (barrier, shearing and mixing zone) guarantees a uniformed plasticizing effect, and can reduce the pressure on the screw which guarantees a high speed and stable output capacity.
5. High torque gear box has a smart figuration, compact construction, low noise, high carrying capacity, high transmission efficiency can assure long-time trouble-free operation;
6. PCA(pipe air cooling system) of die head largely increase the extrusion speed and decrease the cooling length of extrusion line, and improve quality of inner pipe surface;
7. Intelligent PLC controlling system with human-friendly interface make the operation easily and conveniently;
8. Chip-free cutter ensuing flat and smooth cutting surface of pipe.

200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR 0

200-500mm Single Wall Corrugated Pipe Extrusion Line Plastic PVC/PE/PP/PPR 1

Qingdao Win Win Machinery Co., Ltd. is a new type of high-tech enterprise specializing in R & D and production of extrusion machine. The company's main products -- plastic pipe extrusion complete production line.
Our production technology of single / double wall corrugated pipe machine, carbon spiral pipe machine and solid wall pipe machine has always been in the leading position in the industry. Our products have passed ISO9001-2000 quality certification system, CE certification, SGS certification and gost certification of CIS countries.
If you need plastic extrusion equipment, please feel free to contact me!



Li Bing

Tel:86-132 7834 4832 (Wechat/skype/whatsapp)

E-mail: libing@qdwinwin.cn

Web1: www.qdwinwin.cn

Web2: www.corrugatedpipeextrusionline.com

Address: Jiaoxi Industrial Park, Jiaozhou, Qingdao, Shandong, China
