Product Details:
|
| Plastic Processed: | PP PE | Screw No.: | Single-screw |
|---|---|---|---|
| Specification: | 20-63mm | Motor Power: | 37kw |
| Automation: | Automatic | Warranty: | 1 Year |
| High Light: | 63mm Single Wall Corrugated Pipe Extrusion Line,20mm Single Wall Corrugated Pipe Extrusion Line,100kg/H Single Wall Corrugated Pipe Extrusion Line |
||
Plastic 20-63mm PVC PP PE Single Wall Corrugated Pipe Extrusion Line 60-100kg/H
Technical parameter
| pipe diameter range(mm) | 4.5-9mm | 9-32mm | 32-50mm |
| extruder model | SJ-30 | SJ-45 | SJ-65 |
| motor power(kw) | 4 | 11 | 18.5 |
| capacity(kg/h) | 10 | 40 | 80 |
| cooling way | water or air | water or air | water or air |
| production speed(m/min) | 6-10 | 8-15 | 10-17 |
Prouduct description
PVC PP PE single wall corrugated pipes produced by our single wall corrugated pipe machine have many features such as high intensity,good flexibility,high temperature resistance,resistant to corrosion and abrasion etc.
They has large market which are widely used in the fields of auto wire,electric thread-passing pipes,protective pipes of lamps and lanterns wire,circuit of machine tool,tubes of air conditioner and washing machine and so on.
The corrugated pipe equipment produced by our company has the characteristics of light weight, heat insulation, heat preservation, moisture resistance, flame retardant, acid and alkali resistance, corrosion resistance and so on. It is used in power threading pipes, automobile threading pipes, casings, machine tool products, packaging food machinery, electric locomotives, engineering installations, lamps, automation instruments and other fields.
Our bellows machine has the characteristics of low power consumption, low noise, energy saving, low production cost, high work efficiency, uniform plasticization and extrusion stability, accurate temperature control, continuous and stable production of products, reasonable price, and perfect service. Buy our equipment, we will serve you wholeheartedly, solve your problems, and customers can buy with confidence.
