Product Details:
|
| Plastic Processed: | PP PE | Screw No.: | Single-screw |
|---|---|---|---|
| Production Capacity: | 50-200kg/H | Motor Power: | 37kw |
| Color: | Optinal | Warranty: | 1 Year |
| High Light: | Electrical Single Wall Corrugated Pipe Extrusion Line,PE Single Wall Corrugated Pipe Extrusion Line,PP Single Wall Corrugated Pipe Extrusion Line |
||
Plastic Wire Protect PE PP Electrical Single Wall Corrugated hose Extrusion Line
Product Parameters
|
Mode of extruder
|
SJ30
|
SJ-50
|
SJ65
|
|
Pipe diameter range
|
4.5-9mm
|
9-32mm
|
16-50mm
|
|
L/D of screw
|
30:1
|
30:1
|
30:1
|
|
Production capacity
|
10kg/h
|
30-40kg/h
|
50-100kg/h
|
|
Power of extruder
|
4kw
|
15kw
|
18.5kw
|
|
Power of forming machine
|
1.1kw
|
1.5kw
|
2.2kw
|
|
Pairs of modules
|
50pairs
|
50pairs
|
90pairs
|
|
Cooling mode
|
water cooling &fan cooling
|
water cooling &fan cooling
|
water cooling&fan cooling
|
|
Production speed
|
8-12m/min
|
8-12m/min
|
10-20m/min
|
|
Coiling mode
|
air cooling or water cooling
|
air cooling or water cooling
|
air cooling or water cooling
|
PE PP electrical corrugated hose extrusion line
Plastic Wire Protect PE PP Electrical Single Wall Corrugated hose Extrusion Line can be used to produce corrugated pipes of PE,PP,EVA,PVC continuously, as well as PA corrugated pipes. Plastic single wall corrugated pipes have features of high temperature resistance, corrosion and abrasion resistance, high intensity and good flexibiliry, etc.
Plastic corrugated pipe extrusion line Character
Plastic single-wall corrugated pipe production line developed by our copany adopts gears to run moulds and templates so as to realize water circulating cooling and air cooling of the products, which ensures high-speed molding, even corrugation, smooth inner and outer pipe well.
Plastic corrugated pipe extrusion line application
They are widely used in fields of auto wire harness, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lantern wires, tubes of air conditioner and washing machine,especially used as wires of the up-market cars, etc.
