Product Details:
|
| Driven Type: | Electric/Pneumatic | Total Power: | 2.8kw |
|---|---|---|---|
| Machine Voltage: | 20V,50Hz | Control: | PLC |
| Screw&Barrel: | 30crmoala | Brand: | Win-Win |
| High Light: | Corrugated Soft Tube Extrusion Machine,HDPE Corrugated Tube Extrusion Machine,Soft Corrugated Pipe Extrusion Line |
||
Plastic HDPE PE PP PVC Single Wall Corrugated Pipe Soft Tube Extrusion Making Machine/Production Line
Single screw extruder can process all kind of plastics products with auxiliary machines concerned, such as film, pipe, stick, plate, thread ,ribbon, insulating layer of cable, hollow products and so on .It is also used in graining. The machine design is advanced, production capacity is high, plasticization is good, and energy consumption is low. The extruder adopts hard gear surface for transmission. It has advantages of low noise, smooth operation, large loading, long use-life and so on.
More Pics of Our Machines:
65/30 High Speed Single Wall Corrugated Pipe Machine Extruder
High plasticization rate,uniform melt and continuous production stability. High performance gearbox reducer.
Single screw extruder can process all kind of plastics products with auxiliary machines concerned, such as film, pipe, stick, plate, thread ,ribbon, insulating layer of cable, hollow products and so on .It is also used in graining.
Surface Nitriding,increase the Screw using life and the electric part:ABB converter,Omron temperature control.All the parts using domestic and foreign well-known brands.
The machine design is advanced, production capacity is high, plasticization is good, and energy consumption is low. The extruder adopts hard gear surface for transmission. It has advantages of low noise, smooth operation, large loading, long use-life and so on
Corrugated Pipe Forming Mould:
PP PE corrugated pipe machine:Can carve customer logo,can choose double cavity or three cavity in one set mould,when change the size,just up and down forming machine,no need put out all set mould.can save more long time for customer.
Forming Machine
Production speed 20-30m/min
Plate is 38CrNoAi has high surface hardness.wear resistance and fatigue strength,and has good heat resistance and corrosion resistance,hardenability is not high,used for making nitriding parts with high wear resistance,high faigue strength,considerable
strength and high diamensional precision after treatment.the service life is double than 45#steel Cooling method:water colling
The purple part of the plate is perforated for water circulation can ensure that the forming machine and mould are always keeping in low temperature.the pipe inner side more smooth,increase the production speed and product quality.
Forming machine adjustment:manual control left and right,Electric control up and down.
Double Station Winding Machine
Automatic wiring device,balance the speed match rewinding speed,help winding machine adjust the speed,when the pipe production
slow,will stop rewinding,prevent pipe too tight disconnect.
Feature:
1. Adopt the single screw extruder, and mainly used in extruding PE, PP, ABS, PS, PC, and so on
2. The extruder using the special designed single screw making the product forming well.
3. Screw material: High quality alloy steel-38GrMoAlA, after high-temperature nitriding, nitriding deepth: 0.5-07mm, the surface hardness HV740-940.
4. Barrel temperature control though two section, the cast aluminum ring heater provide the hot temperature while the cooling fan with the help of air control the temperature zone.
5. The reduction box adopt the Germany technical which have long life span, low noise and lower hot.
6. The control panel: AC/DC motor ,SIMENS contactor
Application Areas:
single screw extruder is mainly used to process PE,PP, PPR, PET,ABS,HDPE,LDPE,LLDPE and other plastics. Equipped with auxiliary machies, it can manufacture pipes, profiles ,sheets ,film, granulates and other plastic products.
Technical Parameters:
| Model | L/D | Output(kg/h) | Speed(r/min) | Drive power(kw) |
| SJ-25 | 25/1 | 5 | 20-120 | 2.2 |
| SJ-30 | 25/1 | 10 | 20-180 | 5.5 |
| SJ-45 | 25-33/1 | 50-150 | 20-150 | 7.5-22 |
| SJ-65 | 25-33/1 | 60-250 | 20-150 | 22-90 |
| SJ-75 | 25-33/1 | 200-350 | 20-150 | 55-110 |
| SJ-90 | 25-33/1 | 180-550 | 20-110 | 37-185 |
| SJ-120 | 25-33/1 | 320-800 | 20-90 | 75-280 |
| SJ-150 | 25-33/1 | 400-1200 | 20-75 | 90-355 |
FAQ:
1.Are you manufacturer or trading company?
We are manufacturer for plastic pipe machines, PVC profile machines and plastic recycling machines.
2.Why choose us?
We have 15 years experience for producing plastic machine. Experienced engineers and skilled workers with
good raw material to build the machines with heart and honesty to guarantee the performance of the machines.
3.Delivery time:
40-60 working days.
4.Payment terms:
30% of total amount should be paid by T/T as down payment, the
balance (70% of total amount) should be paid before delivery by T/T or irrevocable
L/C(at sight).
5.After-sales service:
Free Spare Parts ;
Field installation, commissioning and training ;
Field maintenance and repair service ;
Video/Online technical support.
6.Warranty:
12 month
